AV32 Specifications
AVIARA 32 - STANDARDS & OPTIONS STANDARD FEATURES INDIVIDUAL OPTIONS     MONOLITH HELM CANVAS AND COVERS Garmin 12" 7 Series w/Navionics Maps Canvas Full Enclosure - Curtains and Bow Cover 10.1" Control...
bowrider boat, luxury, cruiser, yacht, sport yacht, sport cruiser, luxury bowrider, pleasure boat, boat for entertaining, the best bowrider, sterndrive boat, outboard boat, mercury outboard, ilmore
STERNDRIVE   OUTBOARD  Overall Length  32’ 6” Overall Length  34’ 4” Beam 10’ 4” Beam 10’ 4” Draft Up 1’ 11" Draft Up 1’ 11” Draft Down 3’ 0” Draft Down 2’ 10” Dry Weight ~13,000 Lbs. Dry Weight ~12,000 Lbs. Usable Fuel 166 Gallons Usable Fuel 166 Gallons Fresh Water  21 Gallons Fresh Water  21 Gallons Waste Water 19 Gallons Waste Water 19 Gallons Deadrise 20 Degrees Deadrise 20 Degrees Max Persons/Weight Yacht Certified Max Persons/Weight Yacht Certified AVIARA 32 - STANDARDS & OPTIONS STANDARD FEATURES INDIVIDUAL OPTIONS     MONOLITH HELM CANVAS AND COVERS Garmin 12" 7 Series w/Navionics Maps Canvas Full Enclosure - Curtains and Bow Cover 10.1" Control Screen Mooring Cover (Black Only) - Radio Control, Boat Sys., Depth Finder, Water, Air Temp Power Retractable Sunshade - Aft Ilmor Digital Dashboard (7" - I/O Only) Stowable Sunshade - Aft (N/A w/Power Shade) Mercury Vessel View (7" Simrad - OB only) Stowable Sunshade - Bow  Steering Wheel, Italian Crafted - Color Coordinated   Electric Hydraulic Steering w/Tilt Helm DRIVER AIDES   AutoGlide Automated Trim Tabs KLIPSCH PREMIUM AUDIO Docking Lights - Aft Facing Rubrail ICE Radio Controller (built into the 10.1" Helm Screen) Docking Lights - Bow Rubrail Eight (8) Klipsch 8.5" Speakers Ilmor One Touch Pro Upgrade (I/O Only) Two (2) 11" Subwoofers Mercury Active Trim (OB Only) 8-CH Amplifier & 1-CH Monoblock Amplifier VHF Radio w/Antenna DSP Module - Tuned by Bongiovi Acoustics Windshield Wiper w/Sprayer     HEAD ENTERTAINMENT Porcelain Electric Toilet Cooled Cup Holders at Helm (2)  19 Gallon Waste Holding Tank Cordova Cooler Upgrade, Under Cockpit Seating Dockside Pump-out Cordova Cooler Upgrade, Wetbar (N/A w/Drawer Cooler) Integrated Sink w/Faucet Drawer Cooler - Built in Vaccum Sealed (42 QT) Under-Sink Storage RGB Accent Lighting, Cockpit Upper Storage Cabinet RGB Accent Lighting, Cockpit and Underwater (2) Mirror Stainless Steel Refrigerator   Stereo Remote - Bow WETBAR Stereo Remote - Transom  Integrated Sink w/Faucet   Dedicated Wine Chilling Zone (3 Bottles) SEATING & FLOORING Portable Igloo Cooler w/Dedicated Storage Bow Filler Cushion Support Solid Surface Counter Top Bow Table, Teak Folding Hinged Garbage Receptacle Bow Table, Teak and Filler Cushion Combo Under Counter Storage Cockpit and Head Flooring - SeaDek (Gray or Tan)   Cockpit and Head Flooring - Woven Mat (Gray only) INDIVIDUAL STANDARD FEATURES Cockpit Heater (I/O Only) Fiberglass Hard Top - Integrated Lighting and Speakers Cockpit Table, Teak Folding Gunnel Trim - Black w/Stainless Steel Insert Heated Seats - Helm Thru-Hulls, Chrome Stainless Steel Heated Seats - Helm and Cockpit Six (6) 10" Pull-Up Cleats - Bow, Midship and Stern Transom Barstools-Style Seating (3) Gas Assist Bow Block-off Door - Billet Aluminum   Windshield, Custom Billet Aluminum Header and Frame ADDITIONAL OPTIONS Double Wide Helm Seat w/individual Flip-up Bolster and Slide Battery Charger 110v (Domestic) Trim Tabs w/Switching Engine Flush Kit (I/O Only) Trumphet Horn Fender Clips (6) - Match Metal Accents Sea Strainers (I/O Only) Gel Cell Batteries - Installed (4)  Transom Loungers w/Recline (3) Overboard Discharge w/Macerator Starboard Bow Bench Seat - Removable Shower - Transom Built-in Bow Cooler Submersible Swim Platform - Power (I/O Only) Portable Igloo Cooler w/Dedicated Storage - Under Cockpit Seating Transom Walk-Through Door - Billet Hinged Seat Bases w/Storage - Stainless Steel Gas Assist Shocks Windlass SS Anchor/Rope/Chain & Wash Down Trash Receptacle - Port   Dedicated Fender Storage (4)   Swim Platform Ladder - 4 Step   Storage and Bilge Compartment Lighting   USB Power Outlets - Bow, Cockpit and Helm   12v Outlet - Helm and Transom   Transom Ski Tow (I/O Only)   Fuel System Carbon Canisters   Automatic Bilge Pumps (x4)   Bilge Blower Systerm   Fire Extinguisher   Automatic Engine Compartment Fire Extinguisher (I/O Only)   Electrical Bonding System   Sealed Wiring Harness w/Tinned Wire   Platform SeaDek (Gray or Tan)   Shipping Cover

Specifications

Aviara 32
STERNDRIVE   OUTBOARD

Overall Length
32’ 6”

Overall Length
34’ 4”

Beam
10’ 4”

Beam
10’ 4”

Draft Up
1’ 11"

Draft Up
1’ 11”

Draft Down
3’ 0”

Draft Down
2’ 10”

Dry Weight
~13,000 Lbs.

Dry Weight
~12,000 Lbs.

Usable Fuel
166 Gallons

Usable Fuel
166 Gallons

Fresh Water
21 Gallons

Fresh Water
21 Gallons

Waste Water
19 Gallons

Waste Water
19 Gallons

Deadrise
20 Degrees

Deadrise
20 Degrees

Max Persons/Weight
Yacht Certified

Max Persons/Weight
Yacht Certified

AVIARA 32 - STANDARDS & OPTIONS

STANDARD FEATURES

INDIVIDUAL OPTIONS

MONOLITH HELM CANVAS AND COVERS
Garmin 12" 7 Series w/Navionics Maps Canvas Full Enclosure - Curtains and Bow Cover
10.1" Control Screen Mooring Cover (Black Only)
- Radio Control, Boat Sys., Depth Finder, Water, Air Temp Power Retractable Sunshade - Aft
Ilmor Digital Dashboard (7" - I/O Only) Stowable Sunshade - Aft (N/A w/Power Shade)
Mercury Vessel View (7" Simrad - OB only) Stowable Sunshade - Bow
Steering Wheel, Italian Crafted - Color Coordinated
Electric Hydraulic Steering w/Tilt Helm DRIVER AIDES
  AutoGlide Automated Trim Tabs
KLIPSCH PREMIUM AUDIO Docking Lights - Aft Facing Rubrail
ICE Radio Controller (built into the 10.1" Helm Screen) Docking Lights - Bow Rubrail
Eight (8) Klipsch 8.5" Speakers Ilmor One Touch Pro Upgrade (I/O Only)
Two (2) 11" Subwoofers Mercury Active Trim (OB Only)
8-CH Amplifier & 1-CH Monoblock Amplifier VHF Radio w/Antenna
DSP Module - Tuned by Bongiovi Acoustics Windshield Wiper w/Sprayer

HEAD ENTERTAINMENT
Porcelain Electric Toilet Cooled Cup Holders at Helm (2)
19 Gallon Waste Holding Tank Cordova Cooler Upgrade, Under Cockpit Seating
Dockside Pump-out Cordova Cooler Upgrade, Wetbar (N/A w/Drawer Cooler)
Integrated Sink w/Faucet Drawer Cooler - Built in Vaccum Sealed (42 QT)
Under-Sink Storage RGB Accent Lighting, Cockpit
Upper Storage Cabinet RGB Accent Lighting, Cockpit and Underwater (2)
Mirror Stainless Steel Refrigerator
  Stereo Remote - Bow
WETBAR Stereo Remote - Transom
Integrated Sink w/Faucet
Dedicated Wine Chilling Zone (3 Bottles) SEATING & FLOORING
Portable Igloo Cooler w/Dedicated Storage Bow Filler Cushion Support
Solid Surface Counter Top Bow Table, Teak Folding
Hinged Garbage Receptacle Bow Table, Teak and Filler Cushion Combo
Under Counter Storage Cockpit and Head Flooring - SeaDek (Gray or Tan)
  Cockpit and Head Flooring - Woven Mat (Gray only)
INDIVIDUAL STANDARD FEATURES Cockpit Heater (I/O Only)
Fiberglass Hard Top - Integrated Lighting and Speakers Cockpit Table, Teak Folding
Gunnel Trim - Black w/Stainless Steel Insert Heated Seats - Helm
Thru-Hulls, Chrome Stainless Steel Heated Seats - Helm and Cockpit
Six (6) 10" Pull-Up Cleats - Bow, Midship and Stern Transom Barstools-Style Seating (3) Gas Assist
Bow Block-off Door - Billet Aluminum
Windshield, Custom Billet Aluminum Header and Frame ADDITIONAL OPTIONS
Double Wide Helm Seat w/individual Flip-up Bolster and Slide Battery Charger 110v (Domestic)
Trim Tabs w/Switching Engine Flush Kit (I/O Only)
Trumphet Horn Fender Clips (6) - Match Metal Accents
Sea Strainers (I/O Only) Gel Cell Batteries - Installed (4)
Transom Loungers w/Recline (3) Overboard Discharge w/Macerator
Starboard Bow Bench Seat - Removable Shower - Transom
Built-in Bow Cooler Submersible Swim Platform - Power (I/O Only)
Portable Igloo Cooler w/Dedicated Storage - Under Cockpit Seating Transom Walk-Through Door - Billet
Hinged Seat Bases w/Storage - Stainless Steel Gas Assist Shocks Windlass SS Anchor/Rope/Chain & Wash Down
Trash Receptacle - Port
Dedicated Fender Storage (4)
Swim Platform Ladder - 4 Step
Storage and Bilge Compartment Lighting
USB Power Outlets - Bow, Cockpit and Helm
12v Outlet - Helm and Transom
Transom Ski Tow (I/O Only)
Fuel System Carbon Canisters
Automatic Bilge Pumps (x4)
Bilge Blower Systerm
Fire Extinguisher
Automatic Engine Compartment Fire Extinguisher (I/O Only)
Electrical Bonding System
Sealed Wiring Harness w/Tinned Wire
Platform SeaDek (Gray or Tan)
Shipping Cover
